Name: Drayton Room Thermostat RTS2
SKU: drayton-RTS2
Availability: InStock

Standard room thermostat with LED ‘on’ indicator, utilising electronic sensing to provide accurate temperature control.

Part number	24002
Energy Class	IV = 2% (Acc. EU 811/2013, 812/2013, 813/2013, 814/2013)
Relevant EC directives	2014/35/EU Low Voltage Directive 2014/30/EU Electromagnetic Compatibility Directive 2011/65/EU RoHS Directive
Applied standards	EN60730-1; EN60730-2-9
Setting range	10°C - 30°C
Control accuracy	<0.6ºC at 4º/hour
Ball pressure test	75ºC
Pollution degree	2
Power supply	24-230V a.c./d.c. 50Hz fused 3A double insulated (no earth required)
Mounting	Suitable for surface or conduit box mounting
Wiring	Designed for fixed wiring only, to comply with current IET wiring regulations (BS7671)
Switch type & rating	S.P.S.T 2(1)A 230V a.c.
Ambient operating temperature	0ºC to 40ºC
Ambient storage temperature	–20ºC to 55ºC
Ambient operating humidity (non condensing)	25% to 90%
Ambient storage humidity	15% - 95%

Drayton Room Thermostat RTS2
