Name: Drayton Digistat+ RF Wireless Room Thermostat RF601
SKU: 8148-RF601
Availability: InStock

Drayton’s stylish Digistat+ RF battery powered thermostat with tactile, audible & visual feedback. Featuring a familiar dial control with a digital display to show that the temperature has been set accurately every time.

Part number	Digistat+ RF & SCR: RF601
Energy Class (ErP rating)	IV = 2% (Acc. EU 811/2013, 812/2013, 813/2013, 814/2013)
Relevant EC directives	2014/53/EU Radio Equipment Directive 2006/66/EC Batteries Directive 2011/65/EU RoHS Directive
Applied standards	EN60730-1; EN60730-2-7; EN60730-2-9 \| EN 300 220-2; EN 301 489-3
Setting range	5°C to 30°C
Control accuracy	+0.5ºC @ 20ºC
Temperature resolution	1°C
Radio frequency	433 MHz
Radio signal range	30m typically. The range may be affected by the composition / density and number of walls between the thermostat and receiver
Ball pressure test	75ºC
Pollution degree	2
Power supply	Digistat+ RF: 2 X 1.5V IEC LR6(AA) alkaline batteries SCR (receiver): 230V a.c. 50Hz
Battery life	Digistat+RF: approx. 2 years
Mounting	Digistat+ RF: Suitable for surface or conduit box mounting SCR (receiver): Industry standard wall plate
Wiring	Designed for fixed wiring only, to comply with current IET wiring regulations (BS7671).
Switch type & rating	SCR (receiver): SPDT (volt free) 2(1)A 230V a.c. or 24V a.c./d.c
Ambient operating temperature	0ºC to 40ºC
Ambient storage temperature	–20ºC to 55ºC
Ambient operating humidity (non condensing)	25% to 90%
Ambient storage humidity	15% - 95%
Software class	A
Class of housing protection	IP30

Main Menu

Alpha Cable To Gas Valve 3.017246

Chaffoteaux Britony Diaphragm 60025809-30
